Product Description TORICH ASTM SA-688/SA-688M Welded Austenitic Stainless Steel Feedwater Heater Tuebs heat exchanger stainless steel tubes Standard SA-688/SA-688M OD 15.9-25.4MM WT ≥0.7mm Length 1-12m or according to customers' actual application Steel Grade 304, 304L, 316, 316L, XM-29, 304N, 316N Application Feeduater Heater Tuebs Technology Cold Rolled Hot Rolled Cold Drawn Chemical Requirements Element Grade TP304 TP304L TP304LN TP316 TP316L TP316LN TP XM-29 TP304N ...

TORICH Flat Sided Tube Elliptical Decorative Handrail Wardrobe Welded Stainless Steel 304 316 Oval Tube Elliptical Stainless Steel Oval Tube Steel Grade Q195-Q235,Q345,20#, ss400 etc 304: 0cr18ni9, 0cr17ni8 201: 1cr17mn6ni5n, 1cr13mn9ni1n 316: 0cr17ni12 or as customer’s request OD 40*120, 40*100, 65*114, 55*160, 50*100, 55*80, 55*160, 40*120, 400*60, 40*80, 30*70, 50*25, 25*100, 25*80,etc WT 0.5-12.0mm Surface A: standard B: 400#-600# mirror C: hairline brushed D: seals/marks

Product Description 304 316 304H Stainless steel heat exchanger and boiler tubes heat exchanger stainless steel tubes OD:6-127mm WT:0.5-12mm Grade:304 304H 316 316L etc Keywords:Stainless steel heat exchanger tubes SA213 long steel tubes, make to U bend tubes for boilers and heat exchangers. With strong wood structure box packing by containers loading and shipping. Heater tubes U TUBES with Stainless, Alloy steel grade available, Carbon Steel grade is also available.

SS304 SUS304 316 316L STB340 Heat Exchanger Seamless Stainless Steel Boiler Tube 1.Materials: 304,304L,316L,316 2.Surface Finish: Pickled 3.Application: a) Superheater the high/super-high pressure power boiler, the superheating steam tube, the boiling water pipe, the superheating tube for locomotive boiler. b) Evaporator c) Pressure and heat transmission d) Tube heat exchanger, tube bundle heat exchanger e) Boiler heat exchangers f) Condenser 4.Thickness : 0.3 - 4mm 5.Outer

ASTM312 304 316 310s 2" Stainless Steel Tube For Piping Systems Quick spec: Material: 304 316 etc Standard:A270 A213 A312 Length: 12m max,as per customer's requests,can be cutting into short one. Size range: OD 6-325mm WT 0.5-20mm Application: piping systems Surface: Pickling + annealing or bright annealing or polishing. Equipment: Cold drawing machine Straightener Annealing furnace Pickling Unit Inspection equipment: Optical Spectrum Analyzer Universal material experiment

TORICH SS304 SUS304 316 316L Stb340 13CrMo44 Heat Exchanger Fin Pipe Round Industrial Seamless Stainless Steel Boiler Tube OD:6-127mm WT:0.5-12mm Grade: 304 316 317 etc Seamless stainless Steel pipe coil Coiled heat exchanger Tube SUS304 / 304L / 316L Mechanical Properties: Material Mechanical Properties Tensile Strength ≥ MPa yield strength ≥ MPa Elongation ≥ % T12 415 220 30 TP304 515 205 35 TP304L 458 170 35 TP316 515 205 35 TP316L 485 170 35 TP317 515 205 35 TP317L 515

20mm Bright Annealed pipe Stainless Steel Tubing ASTM A269 TP304/304L , TP316/316L Size range: O.D.: 4.0-760mm W.T.:1-50mm L: according to customer requirement Manufacture: The tubes are made by seamless or welded process. The tubeing can be hot finished or cold finished Heat treatment: All tubes are furnished in the heat-treated condition Mechanical Tests Requirement: Flaring Test (Seamless Tubes) Flange Test (Welded Tubes) Hardness Test Hydrastatic or Nondestructive

2 inch stainless steel tubing for Heat Exchangers / Condensers 304 316 Grade: UNS N02200, UNS N02201 Production: Cold worked, Hot worked Size range: O.D.:6-127mm W.T.:1-30mm L: according to Customer requirement TABLE 2 Chemical Requirements Chemical Compostion Composition, % Element Nicel (UNS N02200) Low-Carbon Nickel (UNS N02201) Ni,A min 99.00 99.00 Cu 0.25 0.25 Fe 0.40 0.40 Mn, max 0.35 0.35 C,max 0.15 0.02 Si,max 0.35 0.35 S,max 0.01 0.01 Delivery Conditions: Symbols

ASTM A270 304 316L Food Industry 320 Grit Inner Polish and Outside Polish Stainless Seamless Steel Pipe Material Grade : American Standard TP304 , TP304L , TP310S , TP316 , TP316L , TP316Ti , TP321 , TP347 , 904L , S31803 Etc European Standard 1.4301 , 1.4306 , 1.4845 , 1.4401 , 1.4404 , 1.4571 , 1.4541 , 1.4550 , 1.4539 , 1.4462 Etc German Standard X5CrNi18-10 , X2CrNi19-11 , X12CrNi25-21 , X5CrNi17-12-2 , X5CrNi17-12-3 , X2CrNiMo18-14-3 , X6CrNiTi18-10 , X6CrNiTb18-10 Etc
