قطع غيار الآلات باستخدام الحاسب الآلي

TORICH EN10253-4 Matte Polished Stainless Steel 2205 Equal Tee Pipe Fitting Type: Equal Tee, Reducing Tee, 45° Lateral Tee, Y Tee, Equal Cross Raw material: Seamless/Welde Pipe, Steel Sheet, Forging Material: 317/L; 304/L; 316/L; 310/S; 309/S; 347/H; 321/321/H; 904/L; 2205 etc Standard: GB/T12459, GB/T13401, GB14383, SH 3408, SH 3409,EN10253-4 EN 10357, ASME B16.9, DIN2605, DIN2607,JIS2312, JIS2313, MSS SP-43 Producing Process: Extrussion moulding, Pressing, Cold-Working,

TORICH ASME B16.9 310S Stainless Steel Concentrate 3/4 Reducers Material: 317/L; 304/L; 316/L; 310/S; 309/S; 347/H; 321/321/H; 904/L; 2205 etc Raw Material: Seamless pipe, Welded pipe, Steel sheet, Forging (High pressure) Producing Process: Extrussion moulding, Pressing, Cold-Working, Machining, Hot-bending, Welded, Heat treatment. Applications: Petrochemical Plant, Fossil Power Plant, Food Machinery, Gryogenics, Petroleum Refining, Nuclear Power Plant Size: seamless 1/2'~12'

TORICH GB/T12459 DN15 to DN600 TP304 304L Stainless Steel 90 Degree Elbow Size: seamless 1/2'~12' (DN15-DN600) welded 1/2'~12' (DN15~DN1200) Standard: GB/T12459, GB/T13401, GB14383, SH 3408, SH 3409,EN10253-4 EN 10357, ASME B16.9, DIN2605, DIN2607,JIS2312, JIS2313, MSS SP-43 Thickness: SCH5S-SCH160 Material: 317/L; 304/L; 316/L; 310/S; 309/S; 347/H; 321/321/H; 904/L; 2205 etc Raw Material: Seamless pipe, Welded pipe, Steel sheet, Forging (High pressure) Producing Process:

ASME B16.9 DIN 2605 SCH5S Seamless and Welded Stainless steel Sanitary Elbow Material: 317/L ; 304/L;316/L;310/S;309/S;347/H;321/321/H;904/L Size: seamless 1/2'~24' (DN15-DN600) welded 1/2'~48' (DN15~DN1200) Standard: ASME B16.9 ; DIN2605 ; JIS Thickness: SCH5S-SCH160 Applications: Dairy, food, beer, beverage, pharmacy, cosmetic, etc DN NPS OD Center to End Center to Center 25 1 32 33.4 25 50 32 1 1/4 38 42.2 32 64 40 1 45 48.3 38 76 50 2 57 60.3 51 102 65 2 1/2 76 73 64 128

Stainless Steel Machining 90 Degree Elbow Malleable Cast Iron

ASME B16.9 DIN 2605 Seamless and Welded Stainless steel 45 Degrees Elbow Material: 317/L ; 304/L;316/L;310/S;309/S;347/H;321/321/H;904/L Applications: Dairy, food, beer, beverage, pharmacy, cosmetic, etc Size: seamless 1/2'~24' (DN15-DN600) welded 1/2'~48' (DN15~DN1200) DN NPS OD Center to End Center to Center 15 1/2 18 21.3 38 76 20 3/4 25 26.7 38 76 25 1 32 33.4 38 76 32 1 1/4 38 42.2 48 96 40 1 45 48.3 57 114 50 2 57 60.3 76 152 65 2 1/2 76 73 95 190 80 3 89 114 228 90 3 1

ASME B16.9 Concentric Reducer Standard ASME B16.9 wraps in several parameters that act as a guideline for the manufacturer of wrought factory-made buttwelding fittings such as elbows, tees, reducers including the Carbon Steel Concentric Reducer etc. The fittings need to conform to the values of the following parameters i.e. overall concentric pipe reducer dimensions, ratings, testing, tolerances, and markings. Depending on the buyer, these reducers are made available between

ASME B16.9 Equal Tee and Reducing Tee Both equal tee and reducing tee have three branches that usually is T-shaped, they provide 90 degree branches and change fluid direction. ASME B16.9 Buttweld tees are widely used in pipe convey. They are very common in industrial applications such as oil and gas transmissions, water treatment system, power station, chemical industry and engineering. ASME B16.9 is manufacture standard for Factory-Made Wrought Buttwelding Fittings. Put

ASTM A350 LF2 / A350 LF3 Carbon Steel Weldolet Standards Standards Designation ASTM A 350 LF2/A|350 LF3 LTCS (Low Temperature Carbon Steel). ASME SA350 LF3/SA350 LF2 Size: DN6~DN150(1/8”~6”) Stainless Steel: ASTM a182 F 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L olets weldolet threadolet sockolet flangeolet. Duplex Steel: duplex 2205 2507 s31803 s32750 s32760 s31254 254smo smo254 904l uns no8904 astm a182 f51
